T-Zaehler

German technology · Turkish manufacturing

A fair sharefor every flat.

We measure the heat and water each flat uses in centrally heated buildings, and split the cost fairly, by the regulation and in a way everyone understands.

Request a free survey Explore products
T-Zaehler ZUK-20 ultrasonic heat meter
Standard
EN 1434
Approval
CE and MID
Battery
Up to 10 years
Reading
RF and M-Bus
  • EN 1434
  • MID
  • CE
  • OIML R75
  • OMS
  • M-Bus
  • LoRa
  • RF
  • GPRS
  • EN 13757
  • IP65
  • Made in Türkiye

Product family

Five products. One system.

From the meter in each flat to the reading unit in the boiler room, we make, install and service all of the hardware ourselves.

01 · Ultrasonic calorimeter

Heat Meter

The ZUK series calculates the energy used from the flow and temperature difference of the heating water entering the flat. With no moving parts, its accuracy does not drift over the years.

  • DN15 – DN40
  • Class 2
  • IP65
  • MID

View heat meter

02 · Hot and cold water

Water Meter

A brass-bodied meter with an eight-digit register for domestic water, with communication modules that fit the building's reading network.

  • MID
  • R80
  • M-Bus, LoRa, RF

View water meter

03 · Flow-limiting

Differential Pressure Valve

Balances the heating system hydraulically without electricity, removing temperature differences between floors and valve noise, and letting pumps work less.

  • 5 – 25 kPa
  • DN20
  • PN25

View valve

04 · Apartment heat station

Heat Interface Unit

Each flat produces its own heating and instant hot water in its own station: stainless plate heat exchanger, meter and valves in one compact unit.

  • 33 – 65 kW
  • Stainless 316
  • DN20 · PN10

View station

05 · Central reading unit

M-Bus GSM Converter

Reads every meter in the building over a single cable and passes the data to the management PC or, via GPRS, to a remote server.

  • Up to 500 meters
  • USB, RS485
  • GPRS

View converter

Building section: heat flows from the boiler room to the flats; meter data travels over the M-Bus line to the reading unit and on to the server via GPRS Boiler room M-BUS Server GPRS M-Bus

How it works

From flat to report, seamless data.

  1. Measure

    Heat and water meters in every flat continuously measure and log consumption.

  2. Collect

    Meters connect to the reading unit in the boiler room over a single M-Bus line or RF.

  3. Allocate

    Data reaches the server via GPRS; the software calculates each share by the regulation and prepares a clear report for every flat.

In numbers

Years in the field, day-one accuracy.

10yrsBattery life depending on use, maintenance-free.
<7µAQuiescent current; very low energy use.
500Meters on a single M-Bus reading unit.
Class2EN 1434 accuracy, MID approved.

Process

From survey to the first bill

How we bring the system into service in a building, working with the management at every step.

  1. Survey

    We inspect the installation, existing infrastructure and usage on site.

  2. Design

    We plan device locations, the reading network and where the data goes.

  3. Installation

    Meters are labelled and fitted; the reading unit and network are commissioned.

  4. Test reading

    The first reading and test report confirm the calculation rules together with you.

  5. Periodic billing

    Each period we read, calculate the shares and share the reports with residents.

A person working at a laptop with a T-Zaehler heat meter in front
German engineering, made in Türkiye

Why T-Zaehler

One partner from metering to reporting.

  • European-standard hardwareEN 1434 and MID approved devices that work with open standards such as OMS, M-Bus and LoRa.
  • Local production, fast serviceManufacturing and assembly in Türkiye mean spare parts and field support without delay.
  • Fully regulation-compliantThe formulas, 15 °C correction and special cases of the Turkish heat cost allocation regulation are built in.
  • Transparent reportsEvery report explains how each share was calculated, in plain language.

About us

Cover of the T-Zaehler 2026 product catalogue

Catalogue

Every technical detail in one file.

Specifications, dimensions and installation notes for every product. Download it for your project file.

Download catalogue PDF, 8 MB Browse page by page

Free survey

Let's measure
your building.

Tell us the number of flats and the installation type; after the survey we'll prepare the device list and quote.

Fill in the quote form Contact us
Office+90 312 247 17 24 WhatsApp+90 532 725 10 72 E-mailinfo@t-zaehler.com
